RT / RTx Schematics
wc_tx003865gb_FM10.fm
153
14.2 Electrical Schematic Components—Kohler
Ref. Description
1 Receiving eye—middle
2 Diagnostic tool
3 Module—engine control module (ECM)
4 Voltage regulator
5 Starter
6 Engine ground
7 Internal alternator
8 Relay—glow plugs
9 Relay—throttle pull
10 Relay—Power decoder
11 Fuse—decoder/display
12 Circuit breaker
13 Battery
14 Fuse—engine control module (ECM)
15 Charge port
16 Key switch
17 Throttle switch
18 Module—display
19 Hydraulic valve ground
20 Module—decoder
21 Plug—trailer
22 Hydraulic valves
23 Receiving eye—rear
24 Light ring—rear
25 Sensor—temperature
26 Snubber harness
27 Solenoid—throttle
28 Solenoid—fuel energize to open
29 Receiving eye—front
30 Light ring—front
31 Sensor—oil pressure
32 Sensor—air filter
33 Terminal ring
34 Engine glow plugs
Wire Colors
BK Black RD Red YL Yellow OR Orange
GN Green TN Tan BR Brown PU Purple
BU Blue VIO Violet CL Clear SH Shield
PK Pink WH White GY Gray LB Lt. blue
Ref. Description
To Next Page
