RT / RTx Schematics
wc_tx003865gb_FM10.fm
173
14.22 Electrical Schematic Components — Compatec Compaction
Display (if equipped)
14.23
Ref. Description
1 Fuse—decoder/display
2 Relay mini 50A
3 LED display
4 Sensor
5 Diagnostic port
6 Module—Compatec
Ground—battery minus (DG)
Ignition—battery plus (UB)
Power supply display (US-D)
Control line display (OC)
Signal ground display (SG3)
Power supply sensor (US1)
Input sensor (AE1)
Signal ground sensor (SG1)
RS232 interface (TxD)
RS232 interface (RxD)
RS232 signal ground (SG4)
BSL
7 Module—decoder
Ground
12 VDC output
8 Plug—trailer
Ground
12 VDC input
Wire Colors
BK Black RD Red YL Yellow OR Orange
GN Green TN Tan BR Brown PU Purple
BU Blue VIO Violet CL Clear SH Shield
PK Pink WH White GY Gray LB Lt. blue
To Next Page
