RT / RTx Schematics
wc_tx003865gb_FM10.fm
157
14.6 Electrical Schematic Components—Kohler
Ref. Description
20 Module—decoder
Ground
12 VDC input
Starter
Fuel valves
Light ring—amber rear
Light ring—amber front
12 VDC—receiving eye, front
Ground—receiving eye, front
Data—receiving eye, front
12 VDC—receiving eye, rear
Ground—receiving eye, rear
Data—receiving eye, rear
Reverse
Forward
Ground
Steering—left
Steering—right
Ground
Vibration—high
Vibration—low
Ground
High speed
Brake
Ground
Ground
12 VDC output
21 Plug—trailer
Ground
12 VDC input
22 Hydraulic valves
Reverse
Ground
Forward
Ground
Steering—left
Ground
Steering—right
Ground
Vibration—high
Ground
Vibration—low
Ground
High speed
Ground
Brake
Ground
23 Receiving eye—rear
Signal
Ground (shield)
12 VDC
24 Light ring—rear
Light—amber
Lights—red
Ground
(Not used)
