RT / RTx Schematics
wc_tx003865gb_FM10.fm
163
14.12 Electrical Schematic Components—Kubota
Ref. Description
1 Receiving eye—middle
2 Diagnostic tool
3 Module—engine control module (ECM)
4 Alternator with voltage regulator
5 Starter
6 Engine ground
7 Relay—glow plugs
8 Relay—throttle pull
9 50A fuse—glow plugs, throttle, and alternator
10 50A fuse—stop solenoid
11 Terminal ring
12 Engine glow plugs
13 Stop solenoid
14 Relay—power decoder
15 5A fuse—alternator
16 20A fuse—decoder/display
17 20A fuse—engine control module (ECM)
18 Battery
19 Charge port
20 Key switch
21 Throttle switch
22 Module—display
23 Module—decoder
24 Plug—trailer
25 Hydraulic valves
26 Receiving eye—rear
27 Light ring—rear
28 Receiving eye—front
29 Light ring—front
30 Sensor—oil pressure
31 Sensor—air filter
32 Sensor—water temperature (glow plug thermistor)
33 Sensor—water temperature (high water temperature)
34 Snubber harness
35 Solenoid—throttle
Wire Colors
BK Black RD Red YL Yellow OR Orange
GN Green TN Tan BR Brown PU Purple
BU Blue VIO Violet CL Clear SH Shield
PK Pink WH White GY Gray LB Lt. blue
