52 HC 35 E • HC 45 E • HC 55 E
g
12.3 Spare parts list for the material feed pump
HC 45 E • HC 45 E-SSP • HC 55 E • HC 55 E-SSP
(spare parts diagram, see page 121)
HC 45 E HC 45 E-SSP HC 55 E HC 55 E-SSP
Item Order No. Order No. Order No. Order No. Description
1 0349 473 0349 473 0349 473 0349 473 Cover (2)
2 0349 472 0349 472 0349 472 0349 472 Screw (2)
3 0349 406*(**) 0349 406*(**) 0349 406*(**) 0349 406*(**) Spiral ring
4 0349 407 0349 407 0349 407 0349 407 Connection pin
5 0349 612 0349 612 0349 612 0349 612 Adapter
6 0349 409*(**) 0349 409*(**) 0349 409*(**) 0349 409*(**) Packing, complete (2)
7 0349 410 0349 410 0349 410 0349 410 Conical spring
8 0349 596* 0349 596* 0349 411* 0349 411* Piston rod
9 0349 412 0349 412 0349 412 0349 412 Flange bushing
10 0349 413 0349 413 0349 413 0349 413 Pressure spring
11 0349 622 0349 622 0349 622 0349 622 Ball guide
12 0349 414*(**) 0349 414*(**) 0349 414*(**) 0349 414*(**) Ball
13 0349 634 0349 634 0349 634 0349 634 Outlet valve seat
15 0349 408*(**) 0349 408*(**) 0349 408*(**) 0349 408*(**) O-ring
16 0349 606* 0349 606* 0349 416* 0349 416* Cylinder
17 0349 417*(**) 0349 417*(**) 0349 417*(**) 0349 417*(**) O-ring
18 0349 597 –––––––– 0349 418 –––––––– Ball guide
19 0349 419** –––––––– 0349 477*(**) –––––––– Ball
20 0349 621 –––––––– 0349 420 –––––––– Inlet valve housing
21 0349 300 –––––––– 0349 300 –––––––– Suction tube
0349 714* 0349 714* 0349 701* 0349 701* Service set: material feed pump
0349 715** 0349 715** 0349 702** 0349 702** Service set: valves and packings
9992 504 9992 504 9992 504 9992 504 250 ml separating oil (Mesamoll)
Accessories and spare parts
12.4 Spare parts list for the shovel valve
HC 45 E-SSP • HC 55 E-SSP
(spare parts diagram, see page 122)
Item Order No. Description
1 0349 580 Suction tube
2 9971 489 O-ring 47 x 2.5
3 9910 712* Cap nut M 6 (2)
4 0349 543* Shovel valve
5 0349 544* Shovel valve plate
6 9920 311* Washer (2)
7 0349 545* Rod
9 0349 546 Inlet
11 9971 353* O-ring 21 x 2
12 0349 576* Packing, complete
13 9923 504* Disk spring
14 0349 551 Flat perforated screw
15 9932 048* Spiral pin 3 x 8 (2)
16 3051 267* Clamping sleeve 4 x 8 (2)
17 0349 553 Connection element
Item Order No. Description
19 9910 113* Hexagon nut M 6
20 0349 408* O-ring 50 x 1.78
21 0349 269 Inlet valve housing
23 0349 554 Sealing screw
24 9971 122** O-ring 44 x 2
25 0037 776** Pressure spring
26 0349 556 Ball guide
27 0367 525** O-ring 36.2 x 2.5
28 9941 537** Ball 31.75 mm
30 0349 557** Ball seat
0349 718* Service set: shovel valve
0349 719** Service set: inlet valve –
shovel valve
