56 HC 35 E • HC 45 E • HC 55 E
g
Accessories and spare parts
HC 35 E
HC 45 E HC 55 E
HC 45 E-SSP HC 55 E-SSP
Item Order No. Order No. Description
1 0349 460 0349 460 Fastening angle
2 9903 324 9903 324 Screw M 5 x 16
3 0349 632 0349 632 Tank cover
4 9903 317 9903 317 Screw M 4 x 12
5 0349 302 0349 302 Hexagon screw
6 0349 303 0349 303 Spring washer
7 3055 157 3055 157 Hexagon nut M 10
8 9920 201 9920 201 Washer 10.5
9 0349 306 0349 306 Angle
13 0349 523 0349 540 Belt cover
14 0349 524 0349 541 Lower belt cover
15 0349 559 0349 559 Shaft
16 0349 309 0349 309 Retaining spring
17 0349 571 0349 571 Bushing
18 0349 575 0349 575 Distance sleeve
19 3090 520 3090 520 Clamping sleeve
20 9900 716 9900 716 Cylindrical screw M 5 x 6
21 9922 111 9922 111 Lock washer internal teeth J 5.3
22 9920 202 9920 202 Washer 5.3
23 0349 230 0349 230 Carriage frame
24 0348 349 0348 349 Wheel
25 9994 902 9994 902 Wheel cap
26 0349 572 0349 572 Retention pin
27 9994 268 9994 268 Pressure spring
28 9996 503 9996 503 Key ring
29 0349 641 0349 641 Swivel section
30 3135 463 3135 463 Cylindrical screw M 8 x 12
31 9921 501 9921 501 Spring washer A 8
32 9990 863 9990 863 Stopper
33 0349 640 0349 640 Guard
36 9922 622 9922 622 Round wire snap ring A 25
37 0349 574 0349 574 Handle
38 0349 573 0349 573 Axis
39 9930 607 9930 607 Center-grooved dowel pin 4 x 36
12.8 Spare parts list for the carriage
(spare parts diagram, see page 126)
