HC 35 E • HC 45 E • HC 55 E 55
g
Accessories and spare parts
12.7 Spare parts list for systems with an electric motor
(spare parts diagram, see page 125)
HC 45 E HC 55 E
HC 35 E HC 45 E-SSP HC 55 E-SSP
Item Order No. Order No. Order No. Description
1 0349 588 0349 588 –––––––– Electric motor 230 V~, 50 Hz
–––––––– –––––––– 0349 222 Electric motor 400 V, 50 Hz, V3~
2 9931 039 9931 039 –––––––– Featherkey 8 x 7 x 25
–––––––– –––––––– 9931 042 Featherkey 8 x 7 x 45
3 0349 586 0349 643 0349 535 Pulley
4 –––––––– 0349 644 0349 536 Spring collet
5 0349 587 0349 590 0349 538 Belt
6 9921 601 9921 601 –––––––– Spring washer 8 (4)
–––––––– –––––––– 9921 507 Spring washer A 10 (4)
7 3138 808 3138 808 –––––––– Washer 8.4 (8)
–––––––– –––––––– 9920 201 Washer 10.5 (8)
8 9910 107 9910 107 –––––––– Hexagon nut M 8 (4)
–––––––– –––––––– 9910 105 Hexagon nut M 10 (4)
9 0349 537 0349 537 0349 537 Mounting plate
10 9900 241 9900 241 –––––––– Hexagon screw M 8 x 40 (4)
–––––––– –––––––– 9900 127 Hexagon screw M 10 x 35 (4)
11 0349 653 0349 653 –––––––– Housing
13 0349 677 0349 677 –––––––– Capacitor 60 MF/400-450 V (230 V~, 50 Hz)
14 9953 666 9953 666 –––––––– ON/OFF switch 230 V~, 50 Hz
–––––––– –––––––– 0349 645 ON/OFF switch 400 V, 50 Hz, V3~
15 0349 670 0349 670 0349 670 Control lamp
16 9951 652 9951 652 –––––––– Unit connection line H07RN-F3G2.5 – 6m
–––––––– –––––––– 0349 259 Unit connection line H07RN-F5G2.5 – 6 m
