HC 35 E • HC 45 E • HC 55 E 53
g
Accessories and spare parts
12.5 Spare parts list for the high-pressure filter
(spare parts diagram, see page 123)
HC 45 E-SSP
HC 55 E
HC 35 E
HC 45 E HC 55 E-SSP
Item Order No. Order No. Order No. Description
1 0349 429 0349 429 0349 429 Housing cover
2 0349 430* 0349 430* 0349 430* Pressure spring
3 –––––––– 0349 707 0349 707 Filter cartridge 0 meshes (standard equipment)
0349 707 –––––––– –––––––– Filter cartridge 0 meshes (accessories)
0349 431 –––––––– –––––––– Filter cartridge 5 meshes (standard equipment)
–––––––– 0349 431 0349 431 Filter cartridge 5 meshes (accessories)
0349 704 0349 704 0349 704 Filter cartridge 50 meshes (accessories)
0349 705 0349 705 0349 705 Filter cartridge 100 meshes (accessories)
4 0349 432* 0349 432* 0349 432* Seal thick
5 0349 433* 0349 433* 0349 433* Seal thin
6 0349 434* 0349 434* 0349 434* O-ring
7 0349 435 0349 435 0349 435 Valve seat
8 0349 436 0349 436 0349 436 Housing
9 0349 438 0349 438 0349 438 Sealing screw
10 0349 439 0349 439 –––––––– Double socket NPSM 3/8 inch
–––––––– –––––––– 0349 610 Double socket NPSM 1/2 inch
–––––––– –––––––– 9985 783 Double socket 3/4 inch
11 9970 154 9970 154 9970 154 Sealing ring (2)
12 9991 954 9991 954 9991 954 Manometer
13 0349 615 0349 615 0349 615 Adapter
14 0349 620 0349 620 0349 620 Angle
15 0349 239 0349 239 0349 239 Relief valve
16 0349 618 0349 618 0349 618 Angle
17 0349 619 0349 619 0349 619 Return hose
18 9850 639 9850 639 9850 639 Hose band clamp
0349 700* 0349 700* 0349 700* Service set: high-pressure filter
