WAGNER SPRINT XE Translation Of The Original Operating Manual

Operating manual Manual Powder System SPRINT XE
12 Accessories
Order number 2354920 | Edition 01/2023 59
12.12 CONVERSION SETS
When working with powders that are difficult to feed, the manual system can be converted
into a variant with a 60L vibrator table.
When working with small components or small batches, the manual system can be
converted into a variant with a 3L vibrator table.
Info
The conversion sets have no FM approval!
P_02649
P_02650
Sprint 60 LV Sprint 3 LV
Order no. Designation
2373856 Sprint XE 60L 230V/50Hz conversion set
2383231 Sprint XE 60L 115V/60Hz conversion set (USA/Japan)
2373883 Sprint XE 3L 230V/50Hz conversion set
2383232 Sprint XE 3L 115V/60Hz conversion set (USA/Japan)
12.13 RECIPE STICKER
2x
2x
Tribo Corona
m /h
3.0
0.5
0.3
0.1
1.5
3
Tri
Ø
12
10
11
9
8
m /h
2.0
3
5.5
4.5
3.5
2.5
0 %
100 %
10
20
30
40
50
60
70
80
90
[µA] [Nm³/h] [%][kV]
[Nm³/h]
0.1
> 0.2
@
90 80 4.0 70
50 20 3.6 57
70 40 3.6 50
P5
P6
P7
P8
P9
P10
name 80 100 4.5 80
______________________________
www

www.wagner-group.com/industry
______________________________
2x
82 20 3.6 45
P_01829
Order no. Designation
2331223 Recipe sticker
