Operating manual Manual Powder System SPRINT XE
13 Spare Parts
64 Order number 2354920 | Edition 01/2023
Pos K Stk Order no. Designation
5/6 1 935974 Coupling plug with anti-kink spring
5/7 5 2327855 Velcro cable ties
6 265266 Powder hose set, Ø 11x5000 mm; 0.43x196.85 inches
7 1 130215 Grounding cable, 10 m; 32.81 ft
8 1 241270 Mains cable (Europe)
8 1 264626 Mains cable (USA)
Not included in the scope of delivery, please order separately:
9 1 264268 Powder tank, 60 L
9 1 264224 Powder tank, 25 L
10 1 2331976 Sprint round jet spare parts starter set
10 1 2349959 Sprint flat jet spare parts starter set
13.5 TROLLEY SPARE PARTS LIST
Pos K Stk Order no. Designation
1 1 2307117 Sprint injector bracket, complete
2 ♦ 1 2325026 Bushing, suction tube
3 1 2325022 Retaining clamp
4 2 2362487 Pipe clamp (capacitor seat vibrator motor)
5 2 2305431 Leveling foot
6 1 2305421 Nut
7 ♦ 1 2303279 Guide bush
8 1 2330599 Gun holder
9 ♦ 1 9950817 Cable entry grommet
♦ = wearing parts
