Winterhalter MTR Series User Manual

Machine description | 3 | English
Operating instructions MT Series | 89014484; Version 1 | 17
3.10 Technical data
Temperature default setting
Zone Temperature
Pre-wash zone 840mm (optional) 40 - 50°C
Main wash zone 60 - 65°C
HighTemp (optional): Main wash zone 76°C
Rinse zone (pumped rinse) 60 - 70°C
Rinse zone (fresh water rinse) 80 - 85°C
HighTemp (optional): rinse zone (pumped rinse) 76°C
HighTemp (optional): rinse zone (fresh water rinse) 88°C
Air knife drying zone (optional) 60°C
Drying zone (optional) 60°C
Heat pump (ClimatePlus option)
Description Unit Value
Refrigerant name (in line with ISO 817) - R1234yf
Refrigerant safety group (in line with ISO 817) - A2L
Refrigerant charge kg 3.0
Fluid group (in line with 2014/68/EU) - 1
CO₂ equivalent (IPCC-AR6) t 0.0015
Global warming potential (GWP100, IPCC-AR6) - 0.5
Global warming potential (GWP20, IPCC-AR6) - 1.8
Minimum room size (at 2.5m ceiling height) m
2
18
Max. permissible operating overpressure PS (high-pressure
side)
bar 28
Max. permissible operating overpressure PS (low-pressure side) bar 23
Total heating capacity kW 15 - 24
Exhaust air flow rate m
3
/h 500 - 1350
Exhaust air temperature °C 10 - 23
Relative humidity of exhaust air % 80 - 95
Equipment classification (in line with IEC 60335-2-40:2022) Not accessible to the public
Noise emission
Measured value Noise level
Measurement uncertainty K
pA
2.5dB
Workplace-related emission sound pressure level L
pA
< 70dB
Exhaust air
Observe local guidelines, e.g. DIN EN 16282 / VDI guideline 2052 when constructing the ventilation system.
Operating conditions
Name Unit Value
Temperature at the installation site °C 0 - 40
Relative air humidity at the installation site % < 95
Storage temperature °C > -25
Max. height of the installation location above sea
level
m 3000

Winterhalter MTR Series Specifications

General

Brand	Winterhalter
Model	MTR Series
Category	Dishwasher
Language	English
