Xerox Phaser 3600 Service Manual

Phaser 3600 Printer Service Manual 8-15
Parts List
10 HOLDER BUSHING EXIT (F/DOWN) 013E25770
11 MEA UNIT ROLL EXIT DUPLEX (Duplex Roller) 006N01265
11-1 SHAFT M EXIT DUPLEX
11-2 RMO RUBBER EXIT DUP
12 BUSH M EXIT D7 013N13839
13 GEAR M EXIT DUP Z21 007N01363
14 ELA HOU CST SENSOR (Paper Size Sensor) 130N01461
14-1 PBA SUB CASSETTE
14-2 IPR PLATE SENSOR
14-3 IPR BRACKET SENSOR
15 CBF HARNESS PSIZE
16 GUIDE P REGI UPPER
17 SPRING ETC LEVER
18 HOLDER M BUSHING TX
19 GUIDE PLATE PAPER
20 IPR P GROUND PLATE PAPER
21 PHOTO INTERRUPTER (Outbin Full Sensor) 130N01274
23 CBF HARNESS THERM
24 PMO HOUSING TERMINAL
25 IPR TERMINAL FU
26 CBF HARNESS FUSER
27 CAP M HOUS TERM
28 SHIELD P CTRL
29 GROUND P MOTOR DEVE
30 GROUND P GUIDE TR
31 GROUND P REGI ROLLER
32 GROUND P PICK UP MP
33 GROUND P SCF MAIN
34 GROUND P MOTOR MAIN
35 GROUND P GUIDE DUP
36 CAP M GUIDE HARNESS
37 PMO DUMMY DEVE
38 ELA HOU VARISTOR
39 FOOT ML80
40 PMO REMOVE LOCK CST
PL 1.3 Frame Assembly Parts List Table (continued)
Ite
m
No. Description Part Number

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
