Xerox Phaser 3600 Service Manual

5-4 Phaser 3600 Printer Service Manual
Print-Quality Troubleshooting
Repeating Defects Measurement Table
Control Panel (Internal) Test Print
A test print is available to aid in determining the quality of output from the
printer and to assist in troubleshooting image-quality problem (see Test 8 in
the “Diagnostic Test Menu Map” on page 3-5). Each area of the test print is
used for a image-quality parameter. The following pages explain each of the
ar
eas
and the image-quality parameters. Follow these guidelines when
generating the test print:
■ Use supported paper from a fresh, unopened ream
■ Print five copies of the test print.
■ Discard the first two prints and retain the remaining prints for image-
quality analysis.
Deletions
Inspect the test print for the presence of deletions or unprinted spots. If these
are found, see “Repeating Bands, Lines, Marks, or Spots” on page 5-22.
Repeating Defects
Assembly Component
Distance between
De
fects T
ypical Defect
Print Cartridge Developer Roller 50 mm (1.97 in.) Horizontal image band
Drum 94 mm (3.70 in.) White spots on black
im
age or black spots
on white
Drum Charge
Roll
ers
38 mm (1.50 in.) Black spots
Supply Roller 42 mm (1.65 in.) Light or dark
hori
zontal image
bands
Transfer Roller Transfer Roller 56 mm (2.20 in.) Image ghost
Fuser Assembly Heat Roller 126 mm (4.96 in.) Black spots and image
ghost
Pressur
e Roller 126 mm (4.96 in.) Black spots on back

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
