Xerox Phaser 4510 Service Manual

Phaser 4500/4510 Service Manual 9-41
Parts Lists
Parts List 21.1 Duplex Unit
No. Name/Description Part Number
1 HSG UPPER ASSY (with2-4) 802K46802
2 HSG UPPER DUP
3 SPRING PINCH 809E37140
4 ROLL PINCH 059E97500
6 HSG LOWER DUP P4500: 802E50613
P4510: 848E06510
7 HARNESS ASSY DUP (J50-JD2750)
8 EARTH ASSY PLATE
9 COVER HARNESS
10 SCREW THUMB
11 SCREW HINGE
12 COVER TOP
13 LEVER LATCH RIGHT
14 SHAFT LATCH
15 LEVER LATCH LEFT
16 SPRING LATCH
17 ROLLER DUP 059E97811
18 COVER HSG DUP
19 BEARING DUP 013E22671
20 GEAR ROLLER
21 GEAR IDLE29
22 GEAR IDLE47
23 GEAR IDLE77
24 GEAR IDLE57/37
25 COVER LEFT
26 BRACKET MOTOR
27 SWITCH DUPLEX (P520) 110E10200
28 HARNESS ASSY DUP EARTH (J56-JD560)
29 MOTOR DUPLEX (J51) 127E83202
30 CLAMP EDGE

Xerox Phaser 4510 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	43 ppm
Maximum internal memory	512 MB
Sound power level (standby)	28 dB
Sound pressure level (printing)	56.1 dB
Total input capacity	1350 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	150 sheets
I/O ports	Parallel (IEEE 1284), USB 2.0
Power supply type	220 V
Weight (imperial)	45.2 lbs
Power consumption (active)	675 W
Acoustic power emissions (active, print, copy or scan)	71.9 dB
Envelopes sizes	B5, C5, DL
Custom media width	76 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Coated paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Paper tray media weight	64 - 216 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Supported network protocols (IPv4)	USB/Parallel, 10/100 Base-TX Ethernet
PCL fonts	81
Printer fonts	PCL, PostScript
Maximum duty cycle	250000 pages per month
Recommended duty cycle	25000 pages per month
Number of PostScript fonts	139
Number of print cartridges	1
Display	LCD
Certification	EMC Directive 89/336/EEC, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS 2002/95/EC
Operating temperature (T-T)	41 - 95 °F
Operating relative humidity (H-H)	15 - 85 %
Power consumption (standby)	80 W
Power consumption (PowerSave)	18 W
Package weight	49896 g
Standard interfaces	Ethernet, Parallel, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	630 x 630 x 1194 mm
