Chapter 1: ML605 Evaluation Board
16. Status LEDs
Table 1-19 defines the status LEDs.
Table 1-19: Status LEDs
Designator Signal Name Color Label Description
DS1 SYSACE_STAT_LED GREEN System ACE CF
Status LED
System ACE CF Status
DS2 TI_PWRGOOD and
MGT_TI_PWRGOOD
GREEN POWER GOOD Both UCD9240 controllers
report power good
DS13 FPGA_DONE GREEN DONE FPGA configured successfully
DS23 LED_GRN GREEN STATUS USB JTAG Connection Status
(Dual LED)
LED_RED RED
DS25 12V GREEN 12V 12V Power On
DS27 MGT_AVCC GREEN AVCC GD MGT AVCC Power On
DS28 MGT_AVTT GREEN MGT_AVTT MGT AVTT Power On
DS29 DDR3_VTTDDR_PWRGOOD GREEN DDR3 PWR GD DDR3 VTTDDR Power Good
DS30 SYSACE_ERR_LED RED System ACE CF
Error LED
System ACE CF Error
DS31 FPGA_INIT_B RED INIT FPGA Initialization in progress
DS32 DVI_GPIO1_FMC_C2M_PG GREEN FMC PWR GD FMC Power Good
