DPA Series — DPA80/DPA100 Operating Instructions Page 31
t
a
x
Out 1 Output 1 Gain
Output Gain= +10.2dB
Out 1 Output 1 Polar.
Polarity = [ + ]
Out 1 Output 1 Delay
Delay = 650.0000mS
Output Gain
Variable between -40dB and +15dB in 0.1dB steps.
Output Polarity
Switch between normal [+] and inverted [-] polarity. Note that channel ganging is temporarily
disabled for polarity adjustments.
Output Delay
Max delay time is 650.000mS in 30nS steps. Swap to 1mS steps by pressing ENTER.
Units can be changed to read distance instead of time though the system sub-menu — see
page 47 for details.
