Output Routing
AutoLimiter TimeCst:Yes*
Output Routing
Bridging = None *
Press ENTER to move on to the next output channel or press the channel’s MUTE key to
select it. When all channels have been routed, press ENTER — the unit will run through any
remaining channels (if output 3 had been manually selected, for example, then ENTER would
run through channel 4 before moving on to the final set-up selections).
The next set-up selections are concerned with using automatic time constants for the limiters
and selecting bridged configurations.
The screen will first show:
MC
2
advise setting the limiter time constants automatically. They are based on the frequency
of this channel’s high pass crossover filter. Unless you have a particular reason to not use
the auto setting, set this to YES and press ENTER.
Bridged Mode for Output Pairs
Output pairs can be selected to run in a bridged configuration to realise higher output powers.
When operating in bridged mode, the minimum impedances are doubled.
The minimum load in bridged mode is 4 ohms.
For details of how to connect to the amplifier when running in bridged mode, please see page
16.
Selecting bridged mode is available through the CONFIGURATION > Output Routing menu and
as part of the set-up wizard. Bridged mode is not available for auxiliary output configuration
and should instead be selected on the externally driven “slave “ amplifier.
The screen will show:
Use the encoder to select which channel pairs are to be bridged:
1<>2 - bridge outputs 1 & 2 only
3<>4 - bridge outputs 3 & 4 only
1<>2 & 3<>4 — bridge both output pairs
Confirm selection with ENTER — final section of the configuration wizard will then ask about
resetting/clearing parameters as explained in the next section. If a bridged mode has been
selected there are some changes apparent in the interface to confirm this.
