x
Out 1 - Matrix Gain In A
0.0 Off -40.0 +15.0
Output Matrix Gains
Note that this feature will only be displayed if the configuration for the amplifier or auxiliary
outputs has been set to operate in “Full Matrix” mode , as opposed to “Free Assign” or a
standard routing configuration (1 x 4 way, 2 x 2 way etc.)
To use “Full Matrix” mode, please see the section about adjusting the configuration on page
41.
Initially, the “send” level from Input A will be selected — press ENTER to jump to the next
“send” level for this output. Range is from -40dB to +15.0dB, with Mute one step below -
40.0dB, whereupon the display will show “Off” as for Input B’s send level in the above
example.
