CONFIGURATION Sub-Menu
Input Source Selection
Input Source Selection
Input A = Analogue A
=== Selection Changed ===
Press [ENTER] to CONFIRM
Choosing Sources to Route to Input Processing Channels
To choose sources, from the home screen, press MENU, choose the CONFIGURATION Sub-
Menu and press ENTER.
Use the encoder or BACK and NEXT keys to find the Input Source Selection option and press
ENTER.
The screen will now show the current choice for the first input processing channel (A):
Use the encoder or BACK and NEXT keys to scroll through the eight choices for this input.
These will be:
Four analogue sources:
Analogue A
Analogue B
{Analogue C}
Analogue D
And four digital sources, depending on the AES selection:
AES A
AES B
{Dante C}
{Dante D}
The choices shown above would be shown if AES has been selected on XLR C. Analogue C is
shown in brackets to indicate that this selection will result in no audio, either because the
input is currently unavailable (due to input selection choices in the case of Analogue C) or
because the input does not exist (due to the network audio card not being fitted in the case of
the Dante C and Dante D).
Press ENTER when the required input source is shown, and the next processing channel will
be selected, running through input channels A-D. Finally, if anything has been changed, the
confirmation screen will show:
Press ENTER to confirm the changes and exit to the home screens.
