1-2. Rear Panel
Figure 2.2.1. Rear Panel
Table 2.2.1. Rear panel connections
NO
Connection Purpose
1
VIDEO IN HD-SDI connectors for video input.
2 AUDIO IN 4/8/16 connectors for audio input.
In case of 16ch, an audio cable is needed from ch 5 to ch 16.
AUDIO OUT 1 connector for audio output.
3 HDMI OUT HDMI connectors for main video output.
4 VGA Connector for VGA monitor.
5 RS-232C For engineering use only, the function be used by a gender through the
