3. Set the conditions and click OK button. Then still-image is saved.
8-4. Bi directional audio
The UMS Client allows for bi directional audio between the client and a dvr unit. On the PC, to use bi
directional audio, you will need a sound card of handling a microphone and speakers. On the dvr side, you
will need to connect a microphone to the audio in connection, and a pair of amplified speakers to the audio
out connection.
8-5. Remote search mode and functions
Button Function Description
DATE & TIME Displays the recording time of the data
selected on the time bar at the bottom of the
main user interface.
DISCONNECT Disconnect network connection..
LIVE Switches the search mode to live mode.
To Next Page
