Operation Multi 3410
101
ba75863y18 01/2015
Note
The following rule applies: With the exception of the menus, shortly
pressing the <PRT> key generally outputs the display contents to the
interface (displayed measured values, measuring datasets, calibration
records). If there is a USB-B connection (such as to a PC) at the same
time, the data are output only to the USB-B interface.
4.12.5 Data transmission to the USB-A interface (USB memory
device)
Via the USB-A interface, you can transmit data to a USB memory or
USB printer device. How to transmit data to a USB printer device is
described in an extra section (see section 4.12.5).
The following table shows which data are transmitted to the interface in
which way:
Stored measured
values
Manual  Displayed dataset with
<PRT> after calling up from
the storage
 All datasets with the Output
to RS232/USB function
(USB-B interface)
 All datasets with the Output
to USB flash drive or printer
function (USB-A interface)
For details, see section 4.11.3.
calibration
records
Manual  Displayed calibration record
with <PRT>
 All calibration records with
<PRT
_>
For details, see section 4.12.
Automatic  At the end of a calibration
procedure
Data Control Operation / description
Stored measured
values
Manual All datasets with the Output to
RS232/USB function.
For details, see section 4.11.3.
Calibration data
storage
Manual All stored calibration records of
a sensor with the Output to USB
flash drive or printer function.
For details, see the menu for
calibration and measurement
settings of the sensor.
