Multi 3410 Operation
26
ba75863y18 01/2015
4.3 General operating principles
This section contains basic information on the operation of the
Multi 3410.
Operating elements,
display
An overview of the operating elements and the display is given in sec-
tion 1.1 and section 1.2.
Operating modes,
navigation
An overview of the operating modes and navigation of the Multi 3410 is
given in section 4.3.1 and section 4.3.2.
4.3.1 Operating modes
The meter has the following operating modes:
 Measuring
The measurement data of the connected sensor is shown in the
measured value display
 Calibration
The course of a calibration with calibration information, functions
and settings is displayed
 Storage in memory
The meter stores measuring data automatically or manually
 Data transmission
The meter transmits measuring data and calibration records to a
USB-B interface automatically or manually.
 Setting
The system menu or a sensor menu with submenus, settings and
functions is displayed
4.3.2 Navigation
Measured value display In the measured value display, you can
 open the menu for calibration and measurement settings with
<MENU/ENTER> (short
keystroke)
 open the system menu with the sensor-independent settings by
pressing <MENU/ENTER>Storage & config for a <MENU/
ENTER
_>long keystroke, approx. 2 s).
 change the display in the selected measuring window (e. g. pH ><−
mV) by pressing <M>.
