INSTRUMENT AND CONTROL FUNCTIONS
3-9
3
EAU03031
Starter (choke) knob
Starting a cold engine requires a richer
air-fuel mixture, which is supplied by
the starter (choke).
Move the knob in direction
a
to turn on
the starter (choke).
Move the knob in direction
b
to turn off
the starter (choke).
ECA00038
CAUTION:
_
Do not use the starter (choke) for
more than 3 minutes as the exhaust
pipe may discolor from excessive
heat. In addition, extended use of
the starter (choke) will cause after-
burning. If this occurs, turn off the
starter (choke).
_
EAU01889
Seats (XVS650)
Passenger seat
To remove the passenger seat
Remove the nut, and then pull the pas-
senger seat up.
1. Starter (choke) knob “ ” 1. Nut
E_5bn.book Page 9 Monday, November 13, 2000 9:11 AM
