Yamaha 40 User Manual

EMC00010
Chapter 2
BASIC COMPONENTS
MAIN COMPONENTS..............................2-1
OPERATIONS OF CONTROLS AND
OTHER FUNCTIONS ................................2-4
Fuel tank ................................................2-4
Multifunction tiller handle ...................2-5
Remote control .....................................2-8
Choke knob .........................................2-12
Recoil starter handle ..........................2-12
Steering friction adjusting screw......2-12
Trim tab ...............................................2-13
Trim angle adjusting rod...................2-13
Power trim / tilt switch.......................2-14
Warning indicator ..............................2-14
Tachometer.........................................2-15
Trim meter ..........................................2-15
Tilt lock mechanism ...........................2-15
Tilt support lever ................................2-16
Top cowling lock lever.......................2-17
2p connector .......................................2-17
WARNING SYSTEM ..............................2-18
Overheat warning...............................2-18
Oil level warning / oil filter
clogging warning ...............................2-19
GB
63B-9-78-A0-2 2/17/03 4:26 PM Page 2

Yamaha 40 Specifications

General

Full Throttle RPM Range	5000 - 6000 rpm
Fuel Induction System	EFI (Electronic Fuel Injection)
Starting System	Electric
Displacement	747cc
Prop Shaft Horsepower	40hp
Ignition System	TCI
