OPERATIONS OF CONTROLS
AND OTHER FUNCTIONS
EMC21112
FUEL TANK
If your model was equipped with a
portable fuel tank, its function is as fol-
lows.
1 Fuel hose joint
2 Fuel meter(If equipped)
3 Fuel tank cap
4 Air vent screw(If equipped)
w
The fuel tank supplied with this engine is
its dedicated fuel reservoir and must not
be used as a fuel storage container.
Commercial users should conform to rel-
evant licensing or approval authority reg-
ulations.
EMC31010
Fuel hose joint
This connector is provided for connecting
or disconnecting fuel hose.
EMC41110
Fuel meter
This meter is on the fuel tank cap. It
shows current fuel quantity in the fuel
tank approximately.
EMC51010
Fuel tank cap
This cap is for filling fuel. To remove it,
turn it counterclockwise.
EMC61010
Air vent screw
This screw is on the fuel tank cap. To
loosen it, turn it counterclockwise.
