Yamaha 5C User Manual

3-18
GB
CLOSE
3
CLOSE
315021*
EMG40710
STOPPING ENGINE
When stopping the engine, proceed as
follows;
NOTE:
Stopping the engine immediately after
operating at high rpm is not recommend-
ed. Let it cool off for a few minutes at idle
or low speed first.
1) Push and hold the engine stop switch
until the engine comes to a complete
stop.
4/5
The engine can also be stopped by
pulling the lanyard from the engine
stop switch.
2) After stopping the engine, tighten the
air vent screw and set the fuel cock
lever / knob to the closed position.
4/5
3) Disconnect the fuel joints after using
the separate fuel tank.
001500
4/5
3
2
2
4/5
3
6A1-9-7LA0-3A 3/7/02 12:14 PM Page 84

Yamaha 5C Specifications

General

Fuel Induction System	Carburetor
Starting System	Manual
Ignition System	CDI
Gear Ratio	2.08 : 1
Propeller Shaft Horsepower	5 hp
Full Throttle RPM Range	4500 - 5500 rpm
Gear Shift	Forward, Neutral
Cooling	Water
