Yamaha 5C User Manual

GB
2-13
EMD63010
TOP COWLING LOCK LEVERS
3
To remove the engine top cowling, pull
up the front and rear lock levers. Then lift
off the cowling. When replacing the cowl-
ing, check to be sure it fits properly in the
rubber seal. Then lock the cowling again
by moving the levers downward.
4/5
To remove the engine top cowling, push
the lock lever downward. Then lift off the
cowling. When replacing the cowling,
check to be sure it fits properly in the rub-
ber seal. Then lock the cowling again by
moving the lever upward.
301035
301036
3
4/5
6A1-9-7LA0-2 3/7/02 12:13 PM Page 46

Yamaha 5C Specifications

General

Fuel Induction System	Carburetor
Starting System	Manual
Ignition System	CDI
Gear Ratio	2.08 : 1
Propeller Shaft Horsepower	5 hp
Full Throttle RPM Range	4500 - 5500 rpm
Gear Shift	Forward, Neutral
Cooling	Water
