GB
2-12
EMD47010
TILT SUPPORT KNOB
2
To keep the outboard motor in the tilted-
up position, push the tilt support knob
under the swivel bracket.
EMD48010
TILT SUPPORT BAR
3/4/5
The tilt support bar keeps the outboard
motor in the tilted up position.
403022
403041
403016
2
3
4/5
6A1-9-7LA0-2 3/7/02 12:13 PM Page 44

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yamaha 5C and is the answer not in the manual?

Yamaha 5C Specifications

General IconGeneral
Fuel Induction SystemCarburetor
Starting SystemManual
Ignition SystemCDI
Gear Ratio2.08 : 1
Propeller Shaft Horsepower5 hp
Full Throttle RPM Range4500 - 5500 rpm
Gear ShiftForward, Neutral
CoolingWater
