CP33
19
DJACK Circuit Board
DJACK, MVR: 2NA-WG40060
to DM-CN3
INOUTUSBSUSTAINAUX
to DM-CN9 to DM-CN2
FOOT PEDAL
MIDI
Component side
(部品側)
Pattern side
(パターン側)
to AJACK-CN302
MASTER VOLUME
MVR Circuit Board
Component side
(部品側)
Pattern side
(パターン側)
