■ LSI PIN DESCRIPTION（LSI 端子機能表）
PIN
NAME I/O FUNCTION
PIN
NAME I/O FUNCTION
NO. NO.
1 DGND - Digital ground 33 NDP_SEL I Indicates to the HC
2 D2 I/O
34 EOT I EOT input
3 D3 I/O 35 DGND - Digital ground
4 D4 I/O
36 D_SUSPEND O DC 'suspend' state output
5 D5 I/O
37 D_WAKEUP I DC wake-up input
6 D6 I/O 38 /GL O GoodLink LED output
7 D7 I/O
39 D_VBUS I DC USB input
8 DGND - Digital ground 40 H_WAKEUP I HC wake-up input
9 D8 I/O
41 CLKOUT O Programmable clock out
10 D9 I/O
42 H_SUSPEND O HC 'suspend' output
11 D10 I/O 43 XTAL1 I Crystal input
12 D11 I/O
44 XTAL2 I Crystal output
13 D12 I/O 45 DGND - Digital ground
14 D13 I/O
46 /H_PSW1 O Power switching control
15 DGND - Digital ground
47 /H_PSW2 O Power switching control
16 D14 I/O 48 D_DM AI/O USB D- data line for DC
17 D15 I/O
49 D_DP AI/O USB D+ data line for DC
18 DGND - Digital ground 50 H_DM1 AI/O USB D- data line for HC
19 Vhold1 - Voltage holding pin
51 H_DP1 AI/O USB D+ data line for HC
20 NC - No connection 52 H_DM2 AI/O USB D- data line for HC
21 /CS I Chip select
53 H_DP2 AI/O USB D+ data line for HC
22 /RD I Read strobe 54 /H_OC1 I Overcurrent sensing input
23 /WR I Write strobe
55 /H_OC2 I Overcurrent sensing input
24 Vhold2 - Voltage holding pin
56 Vcc - Power supply(3.3V)
25 DREQ1 O HC DMA request 57 AGND - Analog ground
26 DREQ2 O DC DMA request
58 Vreg - 3.3V regulator output
27 /DACK1 I HC DMA acknowledge 59 A0 I Address bus
28 /DACk2 I DC DMA acknowledge
60 A1 I Address bus
29 INT1 O HC interrupt output 61 NC - No connection
30 INT2 O DC interrupt output
62 DGND - Digital ground
31 TEST O test output
63 D0 I/O
32 /RESET I Reset input 64 D1 I/O
DATA bus
DATA bus
DATA bus
DATA bus
ISP1161A1BD (X5879A00) USB CONTROLLER DM: IC027
AK4385ET (X6040A00) DAC (Digital to Analog Converter)
PIN
NO.
NAME
I/O
FUNCTION
PIN
NO.
NAME
I/O
FUNCTION
I Master Clock
Rch Analog out(-)
I Audio Serial Data Clock
Rch Analog out(+)
I Audio Serial Date Input
Lch Analog out(-)
I L/R Clock
Lch Analog out(+)
I Power Down mode
Ground
I Chip Select
Power Supply
I Control Data Input
Rch Data Zero Input Detect
I Control Data Input
Lch Data Zero Input Detect
1
2
3
4
5
6
7
8
MCLK
BICK
SDTI
LRCK
PDN
CSN
CCLK
CDTI
9
10
11
12
13
14
15
16
AOUTR-
AOUTR+
AOUTL-
AOUTL+
Vss
VDD
DZFR
DZFL
O
O
O
O
-
-
O
O
DM: IC011
