Yamaha CP33 - SYSTEM BOOTING FLOWCHART

CP33
51
■ SYSTEM BOOTING FLOWCHART
Control by hardware


Software operation starts from here


Software internal processing




Control by software




Software internal processing




Control by software




Control by software




Control by software










Control by software

Terminal in operation
DM: IC4 16pin (or DM: IC1 4pin)
−
DM: IC4 30pin (or DM: IC29 1pin)
−
DM: IC4 30pin (or DM: IC29 1pin)
DM: IC4 27pin (or DM: CN2 5pin)
DM: IC4 29pin (or DM: CN10 1pin)
DM: IC4 26pin (or DM: CN7 9pin)
PowerOn



SWL01 (Master)
RESET cancelled




CPU
various register settings



SWL01 (Slave)
RESET cancelled



SWL01 (Slave)
operation check



SWL01 (Slave)
RESET
→RESET cancelled


MIDI
RESET cancelled



E-BUS (keyboard, A/D)
RESET cancelled



7-seg. LED
Tempo ("
120")
displayed



MUTE cancelled




Normal operation
available

