Yamaha F115B User Manual

E
2-3
R
N
F
q
w
e
r
t
y
u
u
t
r
y
701031
702032
q
w
e
rr
tty
y
u
u
000323
N
000324
q
w
EMU00098
Remote Control Lever
Moving the lever forward from the
Neutral position engages Forward gear.
Pulling the lever back from Neutral
engages Reverse. The engine will contin-
ue to run at idle until the lever is moved
about 35° (a detent can be felt). Moving
the lever farther opens the throttle, and
the engine will begin to accelerate.
1 Neutral
2 Forward
3 Reverse
4 Shift
5 Fully closed
6 Throttle
7 Fully open
EMU00099
Neutral Interlock Trigger
To shift out of Neutral, the neutral inter-
lock trigger of the remote control lever
must first be pulled up.
EMU00100
Neutral Throttle Lever
To open the throttle without shifting into
either Forward or Reverse, place the
remote control lever in the Neutral posi-
tion and lift the neutral throttle lever.
NOTE:
The neutral throttle lever will operate only
when the remote control lever is in
Neutral. The remote control lever will
operate only when the neutral throttle
lever is in the closed position.
1 Fully open
2 Fully closed
68V-9-13-2 3/15/02 1:59 PM Page 4
