Yamaha F115B User Manual

E
2-9
q
t
w
r
001081
e
y
u
001085
001058
EMU01617
DIGITAL TACHOMETER
This gauge contains the tachometer, trim
meter, hour meter, low oil pressure warn-
ing indicator, and the overheat warning
indicator.
1 Tachometer
2 Trim meter
3 Hour meter
4 Low oil pressure warning indicator
5 Overheat warning indicator
6 Set button
7 Mode button
NOTE:
All segments of the display will light
momentarily after the main switch is
turned on and will return to normal there-
after.
EMU00136
Tachometer
This meter shows the engine speed.
68V-9-13-2 3/15/02 1:59 PM Page 10
