PROCEDURE FOR TILTING UP
Power trim/tilt model
1) If there is a fuel joint or a fuel cock on
the boat, disconnect the fuel line or
close the fuel cock.
2) Push the power trim/tilt switch “UP”
until the outboard has tilted up com-
pletely.
3) Turn the tilt-support lever toward you
and support the engine.
w
After tilting the engine, be sure to sup-
port it with the tilt-support lever.
Otherwise, the engine could fall back
down suddenly if oil in the power
trim/tilt unit should lose pressure.
4) Once the engine is supported with the
tilt-support lever, push the power
trim/tilt switch DOWN to retract the
trim rods.
cC
Be sure to retract the trim rods complete-
ly during mooring. This protects the rods
from marine growths and corrosion
which could damage the power trim/tilt
mechanism.
