E
3-15
ADJUSTING TRIM ANGLE
EMU01401
Power Trim/Tilt Model
w
8 Be sure all people are clear of the out-
board motor when adjusting the
trim/tilt angle, also be careful not to
pinch any body parts between the drive
unit and clamp bracket.
8 Use caution when trying a trim position
for the first time. Increase speed gradu-
ally and watch for any signs of instabili-
ty or control problems.
8 Use the power trim/tilt switch located
on the bottom engine cowling (if
equipped) only when the boat is at a
complete stop with the engine off.
The outboard motor trim angle can be
adjusted operating the power trim/tilt
switch 1.
To raise the bow (“trim-out”), push the
switch UP.
To lower the bow (“trim-in”), push the
switch DN.
Make test runs with the trim set to differ-
ent angles to find the position that works
best for your boat and operating condi-
tions.
NOTE:
To adjust the trim angle while the boat is
moving, use the power trim and tilt
switch located on the remote control
device or tiller handle, if so equipped.
DN
UP
000351
q
68V-9-13-3 3/5/02 9:31 PM Page 16
