E
2-19
000343
000365
q
EMU00163
TOP COWLING LOCK LEVERS
To remove the engine top cowling, pull
up the front and rear lock levers. Then lift
off the cowling. When replacing the cowl-
ing, check to be sure it fits properly in the
rubber seal. Then lock the cowling again
by moving the levers downward.
EMU01146
FLUSHING DEVICE
This device 1 is used to clean the cooling
water passages of the motor using a gar-
den hose and tap water.
NOTE:
Refer to “Cleaning Cooling-water
Passages” in Chapter 4 for instructions on
usage.
68V-9-13-2 3/15/02 1:59 PM Page 20
