E
2-5
NOTE:
The engine cannot be started with the
lock-plate removed.
DN
UP
000328
EMU01112
Power Trim/Tilt Switches
The power trim/tilt adjusts the motor
angle in relation to the transom. The
power trim/tilt switch is located on the
remote control lever grip. Individual-
engine switches are also on the control
cover. Pushing the switch “UP” trims the
motor up, then tilts the motor up.
Pressing the switch “DN” tilts the motor
down and trims the motor down. When
the switch button is released, the motor
will stop in its current position.
NOTE:
8 On the dual engine control, the switch
on the remote control grip controls both
engines at the same time.
8 Refer to the sections “Adjusting Trim
Angle” and “Tilting Up/Down” in
Chapter 3 for instructions on usage.
