E
4-15
000309
q
e
w
r
t
EMU00370
INSPECTING FUEL FILTER
w
Gasoline (petrol) is highly flammable, and
its vapors are flammable and explosive.
8 If you have any question about properly
doing this procedure, consult your
Yamaha dealer.
8 Do not perform this procedure on a hot
or running engine. Allow the engine to
cool.
8 There will be fuel in the fuel filter. Keep
away from sparks, cigarettes, flames or
other sources of ignition.
8 This procedure will allow some fuel to
spill. Catch fuel in a rag. Wipe up any
spilled fuel immediately.
8 The fuel filter must be reassembled
carefully with O-ring, filter cup, and
hoses in place. Improper assembly or
replacement can result in a fuel leak,
which could result in a fire or explosion
hazard.
EMU01282*
NOTE:
If any water is in the fuel, the float 5 will
rise. If so, remove the cup and drain the
water.
1) Remove the nut holding the fuel filter
assembly if so equipped.
2) Unscrew the filter cup 1, catching
any spilled fuel in a rag.
3) Remove the filter element 2, and
wash it in solvent.
Allow it to dry. Inspect the filter ele-
ment and O-ring 3 to make sure they
are in good condition. Replace them if
necessary.
68V-9-13-4 3/15/02 1:59 PM Page 16
