Yamaha F250 User Manual

Components
35
 The free throttle switch can only be used
when the control lever is in the neutral po-
sition.
 During operation the digital electronic con-
trol-active indicator changes from continu-
ously lit to blinking. When the indicator
starts blinking, the throttle begins to open
after the control lever is moved at least
22.5.
 After using the free throttle switch, return
the control lever to the neutral position.
The free throttle switch will return automat-
ically to its set position. The digital elec-
tronic control-active indicator will change
from blinking to continuously lit and the
digital electronic control will then engage
forward and reverse normally.
EMU35252
Throttle friction adjuster
A friction device provides adjustable resis-
tance to movement of the control lever, and
can be set according to operator preference.
To increase resistance, turn the adjuster
clockwise. To decrease resistance, turn the
adjuster counterclockwise.
1. Fully open
2. Fully closed
3. Free accelerator
ZMU05880
FN
ZMU05881
N
1
2
3
22.5
ZMU05882
NF
1. Fully open
2. Fully closed
3. Free accelerator
ZMU05883
N
1
2
3
22.5
6CE-9-36-1E0.book 35 ページ ２０１４年１１月２８日 金曜日 午後２時５５分
©2019 Yamaha Motor Corporation, U.S.A.

Yamaha F250 Specifications

General

Prop Shaft Horsepower	250 hp
Full Throttle RPM Range	5000 - 6000 rpm
Gear Ratio	1.75:1
Starting System	Electric
Displacement	4169cc
Bore x Stroke	96 x 96 mm
Fuel Induction System	EFI (Electronic Fuel Injection)
Ignition System	TCI (Transistor Controlled Ignition)
Alternator Output	50 amps
Steering	Remote
Shaft Length	25 in
Weight	253 kg (557 lbs) - F250XCA
Recommended Fuel	Regular Unleaded (Minimum Octane 87)
