Yamaha F250 User Manual

Instruments and indicators
51
EMU36251
6Y8 Multifunction fuel
management meters
The fuel management meter has the func-
tions of fuel flow meter, total consumption
display, fuel economy display, and remaining
fuel display. The chosen display is selected
by using the “ ” (set) and “ ” (mode)
buttons as described in this section. For
more information, see the operation manual
originally supplied with the meter.
After the main switch is first turned on, all the
displays come on as a test. After a few sec-
onds, the gauge will change to normal oper-
ation.
For more information, see the operation
manual originally supplied with the meter.
EMU41731
Optional meters
Various meters can be installed onto the out-
board motor according to user preference.
For details, consult your Yamaha dealer.
1. Set button
2. Mode button
1. Speedometer
2. Fuel meter
3. Multifunction display
2
1
ZMU05436
1
2
3
ZMU05437
1. Set button
2. Mode button
1. Fuel flow meter
2. Multifunction display
2
1
ZMU05438
1
2
ZMU05439
6CE-9-36-1E0.book 51 ページ ２０１４年１１月２８日 金曜日 午後２時５５分
©2019 Yamaha Motor Corporation, U.S.A.

Yamaha F250 Specifications

General

Prop Shaft Horsepower	250 hp
Full Throttle RPM Range	5000 - 6000 rpm
Gear Ratio	1.75:1
Starting System	Electric
Displacement	4169cc
Bore x Stroke	96 x 96 mm
Fuel Induction System	EFI (Electronic Fuel Injection)
Ignition System	TCI (Transistor Controlled Ignition)
Alternator Output	50 amps
Steering	Remote
Shaft Length	25 in
Weight	253 kg (557 lbs) - F250XCA
Recommended Fuel	Regular Unleaded (Minimum Octane 87)
