Basic components
14
T8
EMU25802
Fuel tank
If your model was equipped with a portable
fuel tank, its function is as follows.
WARNING
EWM00020
The fuel tank supplied with this engine is
its dedicated fuel reservoir and must not
be used as a fuel storage container. Com-
mercial users should conform to relevant
licensing or approval authority regula-
tions.
1. Top cowling
2. Top cowling lock lever
3. Anti-cavitation plate
4. Propeller
5. Cooling water inlet
6. Drain screw
7. Trim rod
8. Clamp bracket
9. Power tilt switch*
10.Manual starter handle*
11.Warning indicator
12.Starter button*
13.Engine stop button/Engine stop lanyard
switch*
14.Gear shift lever*
15.Tiller handle*
16.Steering friction lever*
17.Tilt lock lever*
18.Clamp screw
19.Rope attachment
20.Flushing device
21.Choke knob
22.Remote control box (side mount type)*
