Yamaha F8 - Specifications

Maintenance
47
EMU31480
Specifications
NOTE:
“(AL)” stated in the specification data below
represents the numerical value for the alumi-
num propeller installed.
Likewise, “(SUS)” represents the value for
stainless steel propeller installed and “(PL)”
for plastic propeller installed.
EMU28218
Dimension:
Overall length:
F6MH 1038 mm (40.9 in)
F8MH 1038 mm (40.9 in)
T8EH 1038 mm (40.9 in)
T8PH 1038 mm (40.9 in)
T8PR 552 mm (21.7 in)
Overall width:
F6MH 371 mm (14.6 in)
F8MH 371 mm (14.6 in)
T8EH 371 mm (14.6 in)
T8PH 371 mm (14.6 in)
T8PR 312 mm (12.3 in)
Overall height S:
F6MH 998 mm (39.3 in)
F8MH 998 mm (39.3 in)
Overall height L:
F6MH 1125 mm (44.3 in)
F8MH 1125 mm (44.3 in)
T8EH 1187 mm (46.7 in)
T8PH 1187 mm (46.7 in)
T8PR 1187 mm (46.7 in)
Overall height X:
T8EH 1255 mm (49.4 in)
T8PH 1255 mm (49.4 in)
T8PR 1255 mm (49.4 in)
Transom height S:
F6MH 435 mm (17.1 in)
F8MH 435 mm (17.1 in)
Transom height L:
F6MH 562 mm (22.1 in)
F8MH 562 mm (22.1 in)
T8EH 557 mm (21.9 in)
T8PH 557 mm (21.9 in)
T8PR 557 mm (21.9 in)
Transom height X:
T8EH 625 mm (24.6 in)
T8PH 625 mm (24.6 in)
T8PR 625 mm (24.6 in)
Weight (AL) S:
F6MH 38.0 kg (84 lb)
F8MH 38.0 kg (84 lb)
Weight (AL) L:
F6MH 39.5 kg (87 lb)
F8MH 39.5 kg (87 lb)
T8EH 46.5 kg (103 lb)
T8PH 52.0 kg (115 lb)
T8PR 49.0 kg (108 lb)
Weight (AL) X:
T8EH 47.5 kg (105 lb)
T8PH 53.0 kg (117 lb)
T8PR 50.0 kg (110 lb)
Performance:
Full throttle operating range:
F6MH 4500–5500 r/min
F8MH 5000–6000 r/min
T8EH 5000–6000 r/min
T8PH 5000–6000 r/min
T8PR 5000–6000 r/min
Maximum output:
F6MH 4.4 kW@5000 r/min (6 HP@5000
r/min)
F8MH 5.9 kW@5500 r/min (8 HP@5500
r/min)
T8EH 5.9 kW@5500 r/min (8 HP@5500
r/min)
T8PH 5.9 kW@5500 r/min (8 HP@5500
r/min)
T8PR 5.9 kW@5500 r/min (8 HP@5500
r/min)
Idling speed (in neutral):
1050 ±50 r/min
Engine:
Type:
4-stroke L
Displacement:
197.0 cm³ (12.02 cu.in)
Bore × stroke:
56.0 × 40.0 mm (2.20 × 1.57 in)
Ignition system:
CDI
Spark plug (NGK):
BR6HS-10
