Yamaha MT-09 SP User Manual

Description
3-2
3
EAU10421
Right view
8
2,3 4,51
678910811
1. Fuel tank cap (page 4-17)
2. Spring preload adjuster (page 6-45)
3. Rebound damping force adjuster (page 6-45)
4. Fast compression damping force adjuster (page 6-45)
5. Slow compression damping force adjuster (page 6-45)
6. Coolant reservoir (page 9-13)
7. Engine oil level check window (page 9-10)
8. Engine oil filler cap (page 9-10)
9. Brake pedal (page 6-39)
10.Spring preload adjuster (page 6-48)
11.Rear brake fluid reservoir (page 9-20)
UBMME0E0.book Page 2 Tuesday, March 12, 2024 2:37 PM

Yamaha MT-09 SP Specifications

General

Displacement	889cc
Bore x Stroke	78.0 mm x 62.1 mm
Compression Ratio	11.5:1
Maximum Torque	93.0 Nm (9.5 kg-m) @ 7, 000 rpm
Fuel System	Fuel Injection
Starter System	Electric
Transmission	6-speed
Final Drive	Chain
Length	2, 090 mm
Height	1, 190 mm
Seat Height	825 mm
Wheelbase	1, 430 mm
Ground Clearance	140 mm
Wet Weight	193 kg
Fuel Tank Capacity	14 L
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Power	119 PS (87.5 kW) @ 10, 000 rpm
Front Brakes	Hydraulic dual disc, 298 mm
Rear Brakes	Hydraulic single disc, 245 mm
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
