Yamaha MT-09 SP User Manual

Instrument and control functions
6-50
6
tions, however such adjustments
are ineffective and may damage
the suspension.
WARNING
EWA10222
This shock absorber assembly con-
tains highly pressurized nitrogen
gas. Read and understand the fol-
lowing information before handling
the shock absorber assembly.
 Do not tamper with or attempt
to open the cylinder assembly.
 Do not subject the shock ab-
sorber assembly to an open
flame or other high heat source.
This may cause the unit to ex-
plode due to excessive gas
pressure.
 Do not deform or damage the
cylinder in any way. Cylinder
damage will result in poor
damping performance.
 Do not dispose of a damaged or
worn-out shock absorber
as-
sembly yourself. Take the shock
absorber assembly to a Yamaha
dealer for any service.
EAU70642
DC connectors
This vehicle is equipped with additional
wiring and DC connector(s) for the in-
stallation of optional electric accesso-
ries.
Consult a Yamaha dealer for more in-
formation regarding the location and
capacity of the DC connector(s) and
about what accessories are capable of
being installed.
EAUA1831
USB Type-C jack
This model is equipped with a 5 V 3 A
USB Type-C jack. The USB Type-C
jack can be used when the main switch
is on.
1. USB jack cap
1. USB Type-C jack
11
11
UBMME0E0.book Page 50 Tuesday, March 12, 2024 2:37 PM

Yamaha MT-09 SP Specifications

General

Displacement	889cc
Bore x Stroke	78.0 mm x 62.1 mm
Compression Ratio	11.5:1
Maximum Torque	93.0 Nm (9.5 kg-m) @ 7, 000 rpm
Fuel System	Fuel Injection
Starter System	Electric
Transmission	6-speed
Final Drive	Chain
Length	2, 090 mm
Height	1, 190 mm
Seat Height	825 mm
Wheelbase	1, 430 mm
Ground Clearance	140 mm
Wet Weight	193 kg
Fuel Tank Capacity	14 L
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Power	119 PS (87.5 kW) @ 10, 000 rpm
Front Brakes	Hydraulic dual disc, 298 mm
Rear Brakes	Hydraulic single disc, 245 mm
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
