Yamaha MT-09 SP User Manual

Special features
4-12
4
EAUA2530
Smart key
When the smart key is turned on and
brought within range, the smart key
system allows you to operate the vehi-
cle without inserting a mechanical key.
If the smart key is turned off, the vehi-
cle cannot be operated even if the
smart key is within operating range of
the vehicle.
The current status of the key can be
checked by briefly pressing the
“ON/OFF” switch.
 Short flash: the key is on
 Long flash: the key is off
To turn the smart key on or off
To turn the smart key on or off, press
the “ON/OFF” switch for one second.
The smart key indicator light will flash.
If the key does a short flash, the key is
on. If the key does a long flash, the key
is off.
To use the mechanical key
Pull out the mechanical key from the
smart key body. After using the me-
chanical key, insert it back into the
smart key.
EAUA3030
Replacing the smart key bat-
tery
Replace the battery in the following sit-
uations.
 The smart key system indicator
light flashes for a few seconds
when the power of the vehicle is
turned on.
 When the smart key indicator light
does not come on when the
“ON/OFF” switch is pushed.
1. “ON/OFF” switch
2. Smart key indicator light
3. Mechanical key
1
2
3
1. Smart key system indicator light “ ”
1
UBMME0E0.book Page 12 Tuesday, March 12, 2024 2:37 PM

Yamaha MT-09 SP Specifications

General

Displacement	889cc
Bore x Stroke	78.0 mm x 62.1 mm
Compression Ratio	11.5:1
Maximum Torque	93.0 Nm (9.5 kg-m) @ 7, 000 rpm
Fuel System	Fuel Injection
Starter System	Electric
Transmission	6-speed
Final Drive	Chain
Length	2, 090 mm
Height	1, 190 mm
Seat Height	825 mm
Wheelbase	1, 430 mm
Ground Clearance	140 mm
Wet Weight	193 kg
Fuel Tank Capacity	14 L
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Power	119 PS (87.5 kW) @ 10, 000 rpm
Front Brakes	Hydraulic dual disc, 298 mm
Rear Brakes	Hydraulic single disc, 245 mm
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
