Yamaha MT-09 SP User Manual

Instrument and control functions
6-43
6
EAUA3200
Seats
Passenger seat
TIP
The passenger seat can be removed
and installed with the mechanical key.
To remove the passenger seat
1. Insert the key into the seat lock,
and then turn it counterclockwise.
2. Lift the front of the passenger seat
and pull it forward.
3. Remove the key. When removing
the key, rotate the key clockwise
to the position it was in when in-
serted.
To install the passenger seat
1. Insert the projections on the front
and rear of the passenger seat as
shown.
2. Insert the key into the seat lock,
and then turn it counterclockwise.
While holding the key turned in the
counterclockwise position, push
down on the seat and slide it back
in place.
3. Remove the key. When removing
the key, rotate the key clockwise
to the position it was in when in-
serted.
Rider seat
To remove the rider seat
1. Remove the passenger seat. (See
page 6-43.)
2. Lift the seat rearward and up to re-
move it.
To install the rider seat
1. Insert the projections on the front
of the rider seat into the seat hold-
er and the projections on the rear
of the rider seat into the hole on
the frame cross member as
shown. Place the rider seat in the
original position.
1. Seat lock
2. Unlock.
2
11
2
1. Projection
2. Seat holder
22
22
22
11
11
UBMME0E0.book Page 43 Tuesday, March 12, 2024 2:37 PM

Yamaha MT-09 SP Specifications

General

Displacement	889cc
Bore x Stroke	78.0 mm x 62.1 mm
Compression Ratio	11.5:1
Maximum Torque	93.0 Nm (9.5 kg-m) @ 7, 000 rpm
Fuel System	Fuel Injection
Starter System	Electric
Transmission	6-speed
Final Drive	Chain
Length	2, 090 mm
Height	1, 190 mm
Seat Height	825 mm
Wheelbase	1, 430 mm
Ground Clearance	140 mm
Wet Weight	193 kg
Fuel Tank Capacity	14 L
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Power	119 PS (87.5 kW) @ 10, 000 rpm
Front Brakes	Hydraulic dual disc, 298 mm
Rear Brakes	Hydraulic single disc, 245 mm
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
