Yamaha MT-09 SP User Manual

Special features
4-14
4
5. Install the O-ring and battery cov-
er.
6. Gently snap the smart key case
closed.
EAUA2552
Main switch
The main switch is used to turn the ve-
hicle power on/off and lock/unlock the
steering. After pushing the main switch
knob and confirmation with the smart
key has taken place, the main switch
can be turned while the smart key sys-
tem indicator light is on (approximately
4 seconds).
WARNING
EWA22722
Never turn the main switch to “OFF”
or “LOCK” while the vehicle is mov-
ing. Otherwise the electrical sys-
tems will be switched off, which may
result in loss of control or an acci-
dent.
TIP
 Do not push the main switch knob
repeatedly or turn the main switch
back and forth beyond normal
use. Otherwise, to protect the
main switch from damage, the
smart key system will temporarily
disable and the smart key system
indicator light will flash. If this oc-
curs, wait until the indicator light
stops flashing before operating
the main switch again.
 In order to conserve battery pow-
er, if the main switch remains on
with the engine off for a few sec-
1. Battery
2. O-ring
3. Battery cover
1
2
3
1. Main switch
2. Main switch knob
1. Smart key system indicator light “ ”
11
22
1
UBMME0E0.book Page 14 Tuesday, March 12, 2024 2:37 PM

Yamaha MT-09 SP Specifications

General

Displacement	889cc
Bore x Stroke	78.0 mm x 62.1 mm
Compression Ratio	11.5:1
Maximum Torque	93.0 Nm (9.5 kg-m) @ 7, 000 rpm
Fuel System	Fuel Injection
Starter System	Electric
Transmission	6-speed
Final Drive	Chain
Length	2, 090 mm
Height	1, 190 mm
Seat Height	825 mm
Wheelbase	1, 430 mm
Ground Clearance	140 mm
Wet Weight	193 kg
Fuel Tank Capacity	14 L
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Power	119 PS (87.5 kW) @ 10, 000 rpm
Front Brakes	Hydraulic dual disc, 298 mm
Rear Brakes	Hydraulic single disc, 245 mm
Front Tire	120/70ZR17
Rear Tire	180/55ZR17
