Storage compartments
Front storage compartment
To unlock the storage compartment
Insert the key in the lock and turn it 1/4
turn clockwise.
To open the storage compartment
when it is unlocked
Turn the knob 1/4 turn clockwise. The
knob will return to its original position
after released.
To close the storage compartment
Push the lid into the original position.
To lock the storage compartment
Insert the key in the lock and turn it 1/4
turn counterclockwise, and then re-
move the key.
WARNING
EWA11191
● Do not exceed the load limit of 1
kg (2 lb) for the front storage
compartment.
● Do not exceed the maximum
load of 185 kg (408 lb) for the ve-
hicle.
Rear storage compartment
There is a storage compartment under
the seat. (See page 3-10.)
WARNING
EWAT1051
● Do not exceed the load limit of 5
kg (11 lb) for the rear storage
compartment.
● Do not exceed the maximum
load of 185 kg (408 lb) for the ve-
hicle.
NOTICE
ECA10080
Keep the following points in mind
when using the storage compart-
ment.
● Since the storage compartment
accumulates heat when ex-
posed to the sun, do not store
anything susceptible to heat in-
side it.
● To avoid humidity from spread-
ing through the storage com-
partment, wrap wet articles in a
plastic bag before storing them
in the compartment.
● Since the storage compartment
may get wet while the scooter is
being washed, wrap any articles
stored in the compartment in a
plastic bag.
1. Lock.
2. Front storage compartment
ZAUM0645
O
P
E
N
OPEN
UNLOCK
LOCK
O
P
E
N
OPEN
UNLOCK
LOCK
O
P
E
N
OPEN
UNLOCK
LOCK
1
2
1. Rear storage compartment
ZAUM0646
1
