INSTRUMENT AND CONTROL FUNCTIONS
3-15
3
EAU45051
Ignition circuit cut-off system
The ignition circuit cut-off system (com-
prising the sidestand switch and brake
light switches) has the following func-
tions.
● It prevents starting when the side-
stand is up, but neither brake is ap-
plied.
● It prevents starting when either
brake is applied, but the sidestand
is still down.
● It cuts the running engine when the
sidestand is moved down.
Periodically check the operation of the
ignition circuit cut-off system according
to the following procedure.
U5B2E1E0.book Page 15 Tuesday, July 22, 2008 2:49 PM
